ELEVATOR BELTS
JET OIL
OIL RESISTANT ELEVATOR BELT
JET OIL
jet oil-icona

COATING:
• SBR / NBR black rubber
• Antistatic
• Vegetal and animal medium fat resistant
• Coating Th. 3+1 :  3 mm pulley side for a better adherence and a longer lifetime • Antiabrasive : ISO 4649< 150 mm3
TEXTILE CARCASS:
• Polyester chain
• Polyamide weft
WORKING TEMPERATURE:
•-25°C to +80°C

jet oil foto eng
Documento senza titolo

TECHNICAL DATA

RUPTURE STRENGTH (N/MM)

315

500

630

800

1000

1250

1600

Number of Plies

2

3

3

4

USE BELT
JET OIL VLE

Thicknesses * (mm) + Coating
Total (mm)

2+1
5,3

2+1
6,2

3+1
7,9

3+1
9,3

Average weight (kg/m2)

6,7

7,8

9,4

11,1

Minimum Roll Diameter (mm)
Covered Pulley

200

315

400

500

Minimum Roll Diameter (mm)
Uncovered Pulley

250

400

500

630

Width maximum advised (mm)

400

630

800

1000

*Tolerances : Coating Thicknesses +/- 0,2 mm — Total Thickness +/- 1mm — Width +/- 1% — +/- 5 mm minimum

Non contractual document
